208 V XMT® with ArcReach® Technology, Cable Length Compensation, and Auto-Line™ Technology enhances welding efficiency and control. This multiprocess power source supports CC/CV welding for versatile applications.
Auto-Line™, 208–575 V
Requires 3- or 1-phase power
ArcReach® Technology
ArcReach capabilities increase jobsite productivity and efficiency by eliminating the time spent tracing weld cables hundreds of feet back to the power source because weld operators can make voltage adjustments at the ArcReach wire feeder or remote.
-
Cable Length Compensation
Cable Length Compensation (CLC™) ensures that the voltage a weld operator sets is the voltage they get by automatically adjusting voltage based on weld cable length, even hundreds of feet away from the power source.
Auto-Line™ Technology
Allows hookup to either single-phase or three-phase primary input voltage, 208-600 volts dependent on the machine, with no manual linking, providing convenience in any job setting. An ideal solution for dirty or unreliable input power.
Adjust While Welding
Weld operators have more control and can Adjust While Welding (AWW™) to make fast, easy weld parameter changes at the wire feeder or remote — even while the arc is on. Only Miller offers this advanced solution.
ArcReach Heater Compatibility
Take charge of your field preheat and bakeout applications up to 600 degrees Fahrenheit (315°C). This system uses induction heating to generate heat in workpieces, so welders can do their own preheating quickly and safely. A part of the ArcReach technology platform, the ArcReach Heater is an accessory for select ArcReach welding power sources.
Processes:
MIG (GMAW)
Pulsed MIG (GMAW-P)
RMD®*
Stick (SMAW)
TIG (GTAW)
Flux-cored (FCAW)
Air carbon arc cutting and gouging (CAC-A)
Rated: 5/16-inch
Induction heating** (Available with ArcReach Heater only)
